Panel Rail™

The Panel railing system uses pre-designed 30" x 30" square modules for level applications. For projects requiring more flexibility, half-panels (approximately 15" wide) and custom-sized panels are also available to ensure a precise fit for any layout.

Yes. While the standard modules are square for level areas, Livers Bronze provides custom raked panels specifically designed for stairs and transitions. These are engineered to maintain the aesthetic consistency of the chosen panel design while accommodating the specific angle (rake) of your staircase.

The system offers "countless combinations" of materials and finishes:

• Posts & Panels: Typically made of extruded aluminum with a wide selection of powder-coated colors and textures.
• Cap Rails: Available in various profiles made from aluminum, stainless steel, bronze, or select wood species (sanded and ready for field finishing).
• Handrails: Options include 1.5” or 2” diameter metal and wood handrails mounted via side brackets.

No, the system is designed to be user-friendly for contractors. It is a pre-engineered, component-based system that is shipped to the jobsite ready to assemble. Each shipment includes complete instructions and detailed shop drawings, allowing a single subcontractor to handle the installation from start to finish.

Yes. The Panel Rail™ product page provides comprehensive technical documentation for design and planning, including:

• Revit files for BIM modeling.
• AutoCAD details.
• Product Specifications in both PDF and Word formats.
• Product Data Sheets.

Yes. The system is designed in compliance with current ADA and ICC/ANSI A117.1 accessibility guidelines, as well as International Building Code requirements. It is engineered to withstand a minimum concentrated load of 200 lbs. applied in any direction at any point on the top rail and complies with ASTM E985 performance standards for permanent metal railing systems.

Livers Bronze creates and assembles the entire Panel railing system, delivering a complete, job-site-ready product. All metal fabrication is performed by a single-source fabricator, and installation is carried out by Livers Bronze or an approved installer, ensuring quality and accountability from shop to site. The full system is manufactured here in the USA.
